BKFL-700 Spice Grinding Machine Complete Set

  • model: BKFL-700
  • capacity: 500kg/h
  • material: stainless steel 304
  • power: 46.5kw
  • delivery time: 25-30 days
  • fineness: 20-120 mesh

We're here to help:  Easy ways to get the answers you need.

Share With:
  • Specifications
Introduction:

This self-suction type BKFL-700 complete set spice gridning machine is an efficient mill for food, spices, grains, etc., Crushing and grading of split materials, and independent operation. The machine has a full-featured , compact structure , stable technical performance , power consumption province , a wide range of application , fineness adjustable , easy maintenance, and other characteristics , all the process after feeding  to the finished product is carried out in the same closed system , with the dust removal processing , no pollution to environmental, it is an ideal machine for food industry and GMP standards.

Main Structures:

By hopper , crushing system ,fan blade device , suction dust removal system and the induced draft system, driving device composed of grinding chamber, hopper , crushing blade , gear ring , sieve , fan blade , discharging by suction pipeline , cyclone , air clock , dust filter bag , induced draft fan and so on .

Technique Parameters

Capacity: around 500 kg/h at 380 micron for spices
Inlet size:10mm
Grinding degree: fine grinding
Outlet mesh size: 10-120 mesh (adjustable by sieve)
Spindle RPM: 0-3050r/min
Main Motor: 30KW
Induced air fan power: 15KW
Discharger power: 1.5KW
Voltage: 380V, 3 phases, 50HZ
Material: High Quality of SUS304 with assurance of thickness and enduring use.
